MCK500
NDL611 ࡀ߭՗ TQFD/TIFFU 曳引轮节径 曳引轮绳槽 额定电流 额定功率 额定转速 额定频率 额定转矩 电机极数 切口角

型号
额定梯速
规格
额定载重
Elv. Load
Spec.
Type
Hz
r/min
A
kW
N·m
m/s
kg Elv. Speed Sheave Dia. Sheave Groove Current Power Speed Freq. Torque Poles β Angle
°
mm
Qfsnbofou!Nbhofu!Tzodispopvt!Hfbsmftt!Usbdujpo!Nbdijof
Roping 曳引比 2:1
බᇒՎ൥௃ᴐᣂజल఺ MCK500 1600-0.5 1600 0.5 480 6×Φ12×17 18 5.6 40 16.0 1330 48
MCK500 1600-0.63 1600 0.63 480 6×Φ12×17 18 7.0 50 20.0 1330 48
MCK500 1600-1.0 1600 1.0 480 6×Φ12×17 27 11.1 80 32.0 1330 48
MCK500 1600-1.5 1600 1.5 480 6×Φ12×17 44 16.6 119 47.6 1330 48
MCK500 1600-1.6 1600 1.6 480 6×Φ12×17 44 17.7 127 50.8 1330 48

MCK500 1600-1.75 1600 1.75 480 6×Φ12×17 44 19.4 139 55.6 1330 48

MCK500 1600-2.0 1600 2.0 480 6×Φ12×17 49 22.1 159 63.6 1330 48

MCK500 1600-2.5 1600 2.5 480 6×Φ12×17 60 27.7 199 79.6 1330 48 95

MCK500 2000-0.5 2000 0.5 480 7×Φ12×17 22 7.0 40 16.0 1660 48

׈ჷ׈࿢ Voltage 380V ှ ႄ б Roping 1:1 / 2:1 MCK500 2000-0.63 2000 0.63 480 7×Φ12×17 22 8.7 50 20.0 1660 48

حקᄛᇗ Elv.Load (1600~2000)kg حקะ෎ Elv.Speed (0.5~2.5)m/s
MCK500 2000-1.0 2000 1.0 480 7×Φ12×17 31 13.9 80 32.0 1660 48
ှႄ੽ࢫࣥ Sheave Diam 480mm / 520mm ۽ ቔ ᇅ Duty S5-40%

ٝ޹֩ࠩ IP Code IP41 ቋնᇠ࣡ᄛ Max. Static Load 10000kg MCK500 2000-1.5 2000 1.5 480 7×Φ12×17 53 20.7 119 47.6 1660 48
धჸ֩ࠩ Ins.Class F ሱ ᇗ Weight 765kg
MCK500 2000-1.6 2000 1.6 480 7×Φ12×17 53 22.1 127 50.8 1660 48
ᇅ ׮ ఖ Brake DC110V 2×1.2A
※ 制动器的电压值表示启动及维持电压。 Brake voltage corresponds to its Start&Sustaining voltage.
MCK500 2000-1.75 2000 1.75 480 7×Φ12×17 53 24.2 139 55.6 1660 48

Ҿጎ؅٫཮ DIMENSIONS MCK500 2000-2.0 2000 2.0 480 7×Φ12×17 61 27.6 159 63.6 1660 48
Roping 曳引比 1:1
Roping 曳引比 1:1

MCK500 800-1.0 800 1.0 520 5×Φ13×18 18 5.6 37 14.8 1440 48

MCK500 800-1.5 800 1.5 520 5×Φ13×18 25 8.3 55 22.0 1440 48

MCK500 800-1.75 800 1.75 520 5×Φ13×18 25 9.7 64 25.6 1440 48
95
MCK500 1000-1.0 1000 1.0 520 6×Φ13×18 21 6.5 37 14.8 1690 48

MCK500 1000-1.5 1000 1.5 520 6×Φ13×18 29 9.7 55 22.0 1690 48

MCK500 1000-1.75 1000 1.75 520 6×Φ13×18 29 11.3 64 25.6 1690 48
注 Remark:
1、本机型亦可用于无机房。 The machine can also be used for machine roomless.
2、样本切口角为推荐值，可根据实际工况要求选择切口角度。The above is recommended value of cut angle,it's optional according to practical condition.
